Difference Between Stainless Steel and Galvanised Steel

Plain carbon steel will still rust quite easily in most environments if not protected. Due to this, there are many ways steel has been modified to prevent corrosion. Two popular solutions are using a stainless steel or galvanised steel. While both steels resist rusting and corrosion, there are important differences between them that should be understood.

What is Stainless Steel?

Stainless steel is able to resist corrosion because of the additional alloying elements in its chemical makeup. While plain carbon steel consists of mostly iron and carbon, stainless steel has substantial additions of chromium to help it resist corrosion. The chromium, and sometimes other alloying elements, are added to the stainless steel during the initial melting process, prior to it being formed into any particular shape.

What is Galvanised Steel?

Galvanised steel is a type of steel that has been coated in a layer of zinc that helps prevent the underlying steel from rusting. This layer is usually quite thin, often measured in thousandths of inches or microns. To create galvanised steel, the zinc layer is typically added well after melting, refining, and shaping of the steel plate or sheet. Sometimes it is even done after manufacturing processes have been performed on it such as bending or welding.

How Does Stainless Steel Resist Corrosion?

Stainless steel resists corrosion because of the added chromium (and sometimes other additional elements). Corrosion occurs on carbon steel when the iron from the steel is allowed to combine with oxygen in its surrounding environment. The chromium in stainless steel is able to prevent this as it combines with the oxygen and forms a passive layer of chromium oxide. This layer of chromium oxide prevents the formation of iron oxide, (also known as rust), in many situations, so long as the chromium content of the steel is great enough. Different grades of stainless steel designate and dictate the required amounts of chromium and other alloying elements, which helps to indicate the level of corrosion resistance.

How Does Galvanised Steel Resist Corrosion?

Galvanised steel resists corrosion because of the zinc coating covering the carbon steel. The zinc layer serves two purposes:

1. It prevents oxygen from coming into contact with the steel, therefore reducing the possibility of corrosion.
2. Even if the zinc coating were to experience minor damage and expose small amounts of iron to the atmosphere, the nearby zinc on the rest of the coating is more reactive than steel. This makes the zinc more likely to attract an oxygen molecule than the iron, which prevents rust from forming on the steel.

The Difference Between Stainless Steel and Galvanised Steel

Stainless steel usually has better corrosion-resistant properties than galvanised steel. If the stainless steel becomes scratched, it can still maintain corrosion resistance around the affected area. However, if the zinc layer of galvanised steel is damaged, it can leave the underlying carbon steel exposed and vulnerable. And because galvanised steel is often dipped in zinc in large sheets then cut to size, the edges where the cuts are made are left exposed making it possible for rust to occur.

Stainless steel is also generally considered to be more aesthetically pleasing than galvanised steel, as stainless typically has a shiny, silver-like color, versus the dull-grey pattern of galvanised steel. However, stainless steel is also often more expensive than galvanised steel.

Applications of Stainless Steel

Stainless steel is typically used in applications where the risk of corrosion is a major concern and not permissible. Areas of use for stainless steel include:

• Food processing equipment
• Pharmaceutical manufacturing equipment
• Aerospace engine components
• Kitchen appliances
• Certain types of fasteners

Applications of Galvanised Steel

Galvanised steel is used for applications where corrosion is not desirable, but small amounts may be permissible and aesthetics are not much of a concern. Applications for galvanised steel include:

• Duct work
• Automotive components
• Some types of fasteners
• Structural beams
• Metal cabinetry
• Railing
• Walkways
• Traffic signs
• Electric poles
